2023 Heliodent Plus intra oral X-ray unit from Dentsply Sirona
(2) in stock
Smart Design for Stable Positioning and Consistent Imaging
Heliodent Plus offers a 0.4 mm focal spot and vibration-free components to ideally support your workflow
Remote Functionality
Operate the Heliodent Plus outside of the X-ray room via a remote control, remote timer, or through a manual release.
Robust and Durable
The robust product design ensures durability, longevity, and security of investment.
Safe and Intuitive Operation
Clear user options and numerous installation configurations support the unique needs of your practice and facilitate a flexible workflow. Patient safety is put in the forefront with a radiation meter to help ensure that there is neither underexposure or overexposure of your patient and their X-ray.
| Power supply | Direct Current (DC) |
| Line voltage | 120 - 240 V |
|
Focal spot (acc. IEC 336) |
0.4 mm |
| Tube voltage | 60-70 kV |
| Tube current | 7 mA |
| Exposure time | 0.01 - 3.2 s, incrementally adjustable |
| Detector media | Freely selectable among film, phosphor plate and digital sensor |
| Arm length | Medium: 1500mm/59.06” ; Long: 1790mm/70.47” , Extra Long: 2040mm/80.31” |
| Installation option | Wall-mounted, on a mobile cart or on a Dentsply Sirona Treatment Center |
